Charging Discovery System
Use cases: EV test, EVSE test, Man-in-the-Middle test
Voltage rating : 1000 V DC
Current rating: 400 A DC
Measurement range DC voltage: 0…1000 V DC
Measurement range DC current: -500 … 500 A DC
Communication signals: CAN communication; CSS1 (opto coupler f); CCS2 (opto coupler g); VCP (opto coupler k); CPD (opto coupler h); all with voltage range of 9…20 V controllable relais: d1, d2, K and M
CHAdeMO protocols: 0.9; 0.9.1; 1.0.0; 1.0.1; 1.1; 1.2; 2.0 (coming soon)
DESCRIPTION
The Scienlab Charging Discovery System was especially developed to analyse the entire charging interface of electric vehicles and charging infrastructure. The modular system design allows to configure the system perfectly according to the test scope. All charging standards like AC and DC charging (CHAdeMO, CCS, GB/T) can be verified and tested with one single test device. Special system variants for EMC testing, high power DC charging with liquid cooled charging cables, available AC and DC power emulators (5-720 kW) as well as ready-to-use test case libaries for all standards complete the product portfolio for charging analysis and makes Keysight the ideal partner for automated conformance-, interoperability-, quality and EMC-compliance testing.
FEATURES
About charger manufacturer
Company description
Keysight Technologies is one of the leading companies for measurement technology conducting business in over 100 countries with more than 12,000 employees. By the aquisition of Scienlab in 2017 Keysight completes its manifold product portfolio with innovative test benches for components used in several E-mobility applications. Most of the global active OEM customers, as well as global acting test houses rely on the long term experience of Scienlab with regards to battery, inverter, BMS test systems and the analysis of the charging process.
Markets covered
Worldwide
EV products
Testing system
